Motobatt Batteries MB9U 12V Replacement AGM Battery
Motobatt Quadflex offers the best balance between AH (ampere hours) and CCA (Cold Cranking Amps -18C). Achieving this by increasing the size of the internal plates, by utilizing the unused space found in other batteries.
This is made possible through our world wide patented innovated cell connection system. Additionally, we enhance the thickness of the grid, the density of the paste, and the weight (content) of the active material to maximize the capacity allowed by its size. Revolutionary to the Battery Market.
FEATURES
- Power Experience up to 30% more capacity and power with the same size as competitor batteries, thanks to its exclusive design
- Safe No need to add acid and risk any accidental spillages
- Durable Thanks to its technology and high quality AGM it is extremely resistant to vibrations or weld breakages
- Maintenance Free Fully sealed and factory activated, it requires no maintenance other than keeping it charged in storage
- Ready to go With a voltage of over 12.5V the battery is ready to use right away
- New improved solid mounted terminals with threaded inserts
FITMENT
Replaces OEM
- YB9A
- YB9AA
- YB9A2
- YB9LA2
- YB9B
- YB9LB
- YB9B2
- YB9LB2
- YB7A
- YB7AA
- YB7LA
- YB7LB
- 12N7-3A
- 12N7-3B
- 12N7D-3B
- 12N7-4A
- 12N7-4B
- 12N9-3A
- 12N9-3A-1
- 12N9-3B
- 12N9-4B-1
Specs
- Battery Type: MB9U
- Voltage: 12V
- Cold Cranking Amps (CCA): 140
- Marine Cranking Amps (MCA): 201A
- Pulse Hot Cranking Amps (PHCA): 385A
- Capacity (10HR): 11Ah
- Weight: 3.40 kg / 7.48 lbs
- Dimensions (L x W x H):
- 5.35 in x 2.99 in x 5.24 in
- 136 mm x 76 mm x 133 mm
- Total Height with Terminals:
- TH1: 5.48 in (139 mm)
- TH2: 6.10 in (154 mm)
- Assembly Figure Terminal Locations: 4
- Terminals: 2, M6 x 2.5 mm (Part# MPT2)
- Screws: 4, M6 x 7 mm (Part# 2x MPS2)
- Allen Wrench: 1, 4 x 4 mm (Part# MPAK2)
- Terminal Caps: 4, 12 x 5.5 mm (Part# 2x MPC2)
- Spacers:
- 2x Bottom Spacers (Part# MPBS2)
- Spacer 1: 6 mm
- Spacer 2: 15 mm
- Total Height with Spacers: 21 mm
ADDITIONAL INFO
UTV battery replacement is essential for maintaining reliable starts and powering electrical systems. A weak or dead battery can prevent your UTV from starting, hinder electrical accessory operation, and even cause issues with the vehicle's electronic systems. Replacing the battery with a high-quality unit ensures consistent starts, reliable power for accessories, and optimal performance from your UTV's electrical components.
